These two datasets along with the scan file is essential for a reverse engineering workflow. The curve drawing tools will help you extract wire-frame geometry and export to IGES format. The region and feature extraction toolkit will help you extract faces or bounded surfaces and export into an IGES or STP format. If your focus is on solid modeling you can use GE to extract CAD data (surfaces and solids) and curve data (wire-frame geometry) from triangular meshes (scan data). There are two ways Geomagic Essentials help with reverse engineering. tend to have problems with large-sized mesh files.
#LED MOVING SIGN MODEL HX SOFTWARE SOFTWARE#
The standard CAD software suites such as Solidworks, Autodesk Inventor, etc.
#LED MOVING SIGN MODEL HX SOFTWARE FULL#
You will save a lot of time with the full Scan to CAD process with Geomagic Essentials in between, not to mention it is much more effective at working with large-sized files. The ExScan software and SolidEdge does have a toolkit for fixing meshes but it is not as extensive or automatic as the tools in Geomagic Essentials.
#LED MOVING SIGN MODEL HX SOFTWARE HOW TO#
Scan data is often-times imperfect, meaning there might be holes and imperfections in the data that you'll be scratching your head on how to fix. It is a 3D design software that can be used to assist with reverse engineering, generative design, convergent and synchronous modeling.įor mesh editing, we strongly recommend acquiring the Geomagic Essentials software for its many tools to analyze and clean mesh data. Moreover, the scanner is supplied with the Solid Edge SHINING 3D Edition.
#LED MOVING SIGN MODEL HX SOFTWARE MANUAL#
For instance, it features such data editing tools as smoothing, simplification, manual and automatic hole filling, and sharpening. It is a professional software for 3D scanning and data processing that offers a variety of advanced options for data editing.
#LED MOVING SIGN MODEL HX SOFTWARE PRO#
The EinScan HX comes with a proprietary ExScan Pro software solution. To begin using the scanner to your heart’s content, just connect it to your computer with the dedicated USB cable and complete the setup as per the manual. Scanning objects with good geometry with the use of markers, feature, hybrid, and texture align modes.Scanning objects with a transparent, black or shiny surface.When using the Rapid Scan Mode, apply a matte spray to scan dark, shiny and transparent objects.For laser mode, there is an outstanding 350mm-610mm depth of field along with a max FOV of 380mm*400mm and 0.05mm - 3mm point distance. In rapid mode, it works within a 200mm-700mm depth of field and provides a 420mm*440mm FOV with a point distance between 0.25 mm – 3 mm. The EinScan HX offers quite a large single-scan range. The Laser Scan Mode allows scanning at up to 480,000 points/s providing a level of accuracy of up to 0.04 mm. The Rapid Scan Mode can provide an up to 0.05 mm accuracy at a speed of up to 1,200,000 points/s. It provides different precision and speed levels depending on the mode selected. The EinScan HX is a handheld 3D scanner that features high accuracy and scan speed. Proceed with the review for further specs. ( Note: the STL files below is what you can achieve after post-processing the raw scans in the mesh-to-CAD editing software.)Īs you can see, with the right toolkit the EinScan-HX can be used to deliver well-detailed mesh and CAD files. Heritage preservation, artifact restorationĬheck out this accurate render of a wheel hub.The scanner can be used in a plethora of different applications, such as:
The recommended object size range for the scanner is between 30 and 300 cm. Thanks to its built-in color camera, the scanner supports full-color capture and allows for texture tracking. Besides, there is a laser scanning mode designed to capture dark-colored models and objects with a reflective surface. It features an innovative hybrid system that employs dual blue LED lights allowing it to enter the rapid 3D scanning mode. The device can boast high-resolution scans, large scan volume, fast scan speed, and a handful of other useful features. It is a premium lightweight device with a futuristic and ergonomic design that can be taken to remote sites for scanning. The Einscan HX is an industrial handheld 3D scanner, combining two light sources: laser and structured light.
